Sunsynk MAX 16kW, 48Vdc Single Phase Hybrid Inverter with WIFI included
#1: SUN-16.0 Storage Systems - Hybrid Inverter
Sunsynk 16kW Data Sheet
Sunsynk 16kW Installation Manual
Sunsynk 16kW 100 Certificate
*Collections are not permitted due to health & safety regulations*
The Sunsynk MAX 16kW is The largest single-phase hybrid Inverter on the market. A low voltage (48V) hybrid inverter suitable for off-grid, grid support, back-up and self-consumption PV systems. Moreover, the inverter can also be used in both three-phase and single phase parallel applications.
Product Features:
- A total of 15 x inverters can be connected in a three-phase configuration (five units per phase) - giving a maximum power output of 240kW.
- 3 x inverters can be connected in a single-phase configuration giving a total power of 48kW.
- Contains 3 x MPPTs to allow for flexible PV array designs and improved efficiency.
- Programmable multiple operation modes: on-grid/off-grid & UPS.
- IP65 protection rating - suitable for most outdoor installations.
- Wi-Fi dongle as standard – enabling remote monitoring via the Sunsynk cloud
- Compatible with leading lithium battery brands such as Hubble Lithium, Pylontech LV, Freedomwon and Kodak (BL3.6)..
Weight: 56 kg
Rated Power: 16,000 W
Min PPT Voltage: 250 V
Max PPT Voltage: 450 V
DC Startup Voltage: 150 V
DC Shutdown Voltage: 0 V
Max Input Voltage: 450 V
Max DC Power: 18,000 W
Max AC Power (5 Minutes): 16,001 W
Surge AC Power (1 Second): 32,000 W
Max DC Current: 66 A
Max DC Inputs: 6
Has DC Fuses: 0
Connector: Screw Terminal
Included Connectors: 12
Euro Efficiency: 97.6 %
Transformer: None
MPPT Quantity : 3
Has Integrated DC Switch: Yes
Warranty: 5 years
