Products (865)

12 x panel 6kW solar & 10.24kWh battery storage with choice of panels Typical summer day expected daily generation: 24kW Typical winter day expected daily generation: 6kW Battery storage charge/discharge rate: up to 5kwh Sunsynk 5kw Data Sheet Sunsynk 5Kw Installation Manual Sunsynk 5Kw Warranty Sunsynk 5Kw G99 Certificate Sunsynk hybrids have the API to connect to Octopus Agile & Flux to buy electricity at cheap rates and even sell back to the national grid at high rates through SEG payments. Our complete solar pv & battery storage kit includes: 12 x Solar panels, any solar panels can be selected from our website of up to £60+vat cost price typically 450-525W 1 x GSL 10.24kwh storage (For additional batteries please add to your cart GSL 10.24kw battery) 1 x SunSynk On & Off grid 5kW AC ECCO hybrid Inverter 12 x Mounting equipment for standard pitched roof in portrait orientation. For Alternative mounting requirements please request a quote. 1 x Electrics pack including solar cable, MC4's, pre-terminated cable, AC & DC Isolators, bi-directional meter The Sunsynk 5kW ECCO hybrid Inverter is the ideal inverter for managing power flow from multiple sources such as solar, main electrical grid and generator. All of the power of the previous Sunsynk model in a smaller package!Product Features: Dual MPPT designCompatible with most Lithium-ion batteries and Lead Acid batteriesMobile App for monitoringIP65 ratedAutomatic switching from Grid-Tied to Off-Grid modeZero export functionUp to 16 units with the same firmware can be paralleledEssential and Non-Essential Loads outputsComes with the Wi-Fi logger and CTCompatible with SolarMan App for Monitoring   Rated Power: 5,000 WMin PPT Voltage: 125 VMax PPT Voltage: 425 VDC Startup Voltage: 150 VDC Shutdown Voltage: 150 VMax Input Voltage: 500 VMax DC Power: 6,500 WMax AC Power (5 Minutes): 5,500 WSurge AC Power (1 Second): 11,000 WMax DC Current: 22 AMax DC Inputs: 2Has DC Fuses: 0Connector: MC4Included Connectors: 0Euro Efficiency: 96.5 %Transformer: NoneMPPT Quantity: 2Has Integrated DC Switch: Yes GSL 10.24kwh LiFePO4 battery Key information 10yr battery warranty & 5yr inverter warranty 90% D.O.D 6,000 life cycle Maximum PV input power: 6500W Maximum charge current: 100A Product Performance 1. This is a multi-function inverter/charger/solar system. 2. Combining functions of inverter, solar charger and battery to offer uninterruptible power support with portable size. 3. LCD display, configure input voltage range for home appliances and personal computers, configure battery charging current based on applications, configure AC/Solar Charge priority. 4. Compatible to mains voltage or generator power, auto restart while AC is recovering. 5. Users can flexibly match battery capacity, standard battery packages or external batteries. 6. It combines a wide PV input range MPPT controller, can convert solar energy from PV to loads directly. 7. Integrated design, Easy transportion and installation. 8. Overload/Over temperature/short circuit protection. 9. Our product are CE/ ROSH/ VDE/ MSDS/ UN38.3/ IEC approved, meeting various certification requirements for different countries. Product Features: -Safety; LiFePO4 LFP Battery, stable and safe. Module, pack, system, triple protection. -Simple Modular design, single person con carry and install it. Space saving; 0.15 sqm foot print. -Interconnection Global cloud plaform Mobile APP. Anytime and anywhere. Open APL, support power internet applications. Take complete control of your inverter by using the Sunsynk App. Start by visiting the Apple App Store, or Google play store and searching "Sunsynk Logger". Alternatively, open your prefered web browser and search www.sunsynk.net. Real time push notifications. For example Instant notification if you have a power cut or you are running on generator, or batteries Change all settings remotely. Our data logger allows you to change and edit all settings remotely from anywhere in the world, provided that you have an Internet connection. Complete control over your Hybrid Inverter. Using our data logger gives you complete control over your hybrid inverter. You will gain access to features that cannot be accessed via the inverter control panel, such as the update / upgrade feature to update the inverter operating system yourself. Real-time monitoring. The majority of our app works in real-time including any changes that you make will instantly update on your inverter. Live stats and monitoring. You have access to multiple stats including live monitoring and reporting. Using this app allows you to see peaks in your energy usage, you can then customize your system to work around this to help you save money on your electricity bills. Reporting. Generate custom reports and graphs to help you monitor and understand how your system is working and where you are saving money. Real-time monitoring. The majority of our app works in real-time including any changes that you make will instantly update on your inverter. Sunsynk is integrated with Octopus Agile, Flux & Go. Our data

14 x panel 6.2kW solar panel kit with 10.24kWh battery storage with choice of panels   Typical summer day expected daily generation: 28kW Typical winter day expected daily generation: 7kW   Battery storage charge/discharge rate: up to 5kWh   Sunsynk 5w Data Sheet Sunsynk 5Kw Installation Manual Sunsynk 5Kw Warranty Sunsynk 5Kw G99 Certificate   Sunsynk hybrids have the API to connect to Octopus Agile & Flux to buy electricity at cheap rates and even sell back to the national grid at high rates through SEG payments. Our complete solar pv & battery storage kit includes: 14 x Solar panels, any solar panels can be selected from our website of up to £60+vat cost price typically 450-525W   1 x GSL 10.24kwh storage (For additional batteries please add to your cart GSL 10.24kw battery)     1 x SunSynk On & Off grid 5kW AC ECCO hybrid Inverter   14 x Mounting equipment for standard pitched roof in portrait orientation. For Alternative mounting requirements please request a quote.   1 x Electrics pack including solar cable, MC4's, pre-terminated cable, AC & DC Isolators, bi-directional meter     The Sunsynk 5kW ECCO hybrid Inverter is the ideal inverter for managing power flow from multiple sources such as solar, main electrical grid and generator. All of the power of the previous Sunsynk model in a smaller package!Product Features: Dual MPPT designCompatible with most Lithium-ion batteries and Lead Acid batteriesMobile App for monitoringIP65 ratedAutomatic switching from Grid-Tied to Off-Grid modeZero export functionUp to 16 units with the same firmware can be paralleledEssential and Non-Essential Loads outputsComes with the Wi-Fi logger and CTCompatible with SolarMan App for Monitoring   Rated Power: 5,000 WMin PPT Voltage: 125 VMax PPT Voltage: 425 VDC Startup Voltage: 150 VDC Shutdown Voltage: 150 VMax Input Voltage: 500 VMax DC Power: 6,500 WMax AC Power (5 Minutes): 5,500 WSurge AC Power (1 Second): 11,000 WMax DC Current: 22 AMax DC Inputs: 2Has DC Fuses: 0Connector: MC4Included Connectors: 0Euro Efficiency: 96.5 %Transformer: NoneMPPT Quantity: 2Has Integrated DC Switch: Yes   GSL 10.24kwh LiFePO4 battery         Key information 10yr battery warranty & 5yr inverter warranty 90% D.O.D 6,000 life cycle Maximum PV input power: 6500W Maximum charge current: 100A   Product Performance 1. This is a multi-function inverter/charger/solar system. 2. Combining functions of inverter, solar charger and battery to offer uninterruptible power support with portable size. 3. LCD display, configure input voltage range for home appliances and personal computers, configure battery charging current based on applications, configure AC/Solar Charge priority. 4. Compatible to mains voltage or generator power, auto restart while AC is recovering. 5. Users can flexibly match battery capacity, standard battery packages or external batteries. 6. It combines a wide PV input range MPPT controller, can convert solar energy from PV to loads directly. 7. Integrated design, Easy transportion and installation. 8. Overload/Over temperature/short circuit protection. 9. Our product are CE/ ROSH/ VDE/ MSDS/ UN38.3/ IEC approved, meeting various certification requirements for different countries.     Product Features: -Safety; LiFePO4 LFP Battery, stable and safe. Module, pack, system, triple protection.   -Simple Modular design, single person con carry and install it. Space saving; 0.15 sqm foot print.   -Interconnection Global cloud plaform Mobile APP. Anytime and anywhere. Open APL, support power internet applications. Take complete control of your inverter by using the Sunsynk App.   Start by visiting the Apple App Store, or Google play store and searching "Sunsynk Logger". Alternatively, open your prefered web browser and search www.sunsynk.net.   Real time push notifications. For example Instant notification if you have a power cut or you are running on generator, or batteries   Change all settings remotely. Our data logger allows you to change and edit all settings remotely from anywhere in the world, provided that you have an Internet connection.   Complete control over your Hybrid Inverter. Using our data logger gives you complete control over your hybrid inverter. You will gain access to features that cannot be accessed via the inverter control panel, such as the update / upgrade feature to update the inverter operating system yourself.   Real-time monitoring. The majority of our app works in real-time including any changes that you make will instantly update on your inverter.   Live stats and monitoring. You have access to multiple stats including live monitoring and reporting. Using this app allows you to see peaks in your energy usage, you can then customize your system to work around this to help you save money on your electricity bills.   Reporting. Generate custom reports and graphs to help you monitor and understand how your system is working and where you are saving money.     Real-time monitoring. The majority of our app works in real-time including any changes that you make will instantly update on your inverter.   Sunsynk is integrated with Octopus Agile, Flux & Go. Our data logger platform has been integrated with Octopus Agile. Having access to these rates, you can setup and monitor your charge and discharge figur

16 x panel 8kW solar panel kit & 10.24kWh battery storage with choice of panels   Typical summer day expected daily generation: 32kW Typical winter day expected daily generation: 8kW   Battery storage charge/discharge rate: up to 5kWh   Sunsynk 8Kw Data Sheet Sunsynk 8Kw Installation Manual Sunsynk 8Kw Warranty Sunsynk 8Kw G99 Certificate   Sunsynk hybrids have the API to connect to Octopus Agile & Flux to buy electricity at cheap rates and even sell back to the national grid at high rates through SEG payments. Our complete solar pv & battery storage kit includes: 16 x Solar panels, any solar panels can be selected from our website of up to £60+vat cost price typically 450-525W   1 x GSL 10.24kwh storage (For additional batteries please add to your cart GSL 10.24kw battery)     1 x SunSynk On & Off grid 8kW AC ECCO hybrid Inverter   16 x Mounting equipment for standard pitched roof in portrait orientation. For Alternative mounting requirements please request a quote.   1 x Electrics pack including solar cable, MC4's, pre-terminated cable, AC & DC Isolators, bi-directional meter     The Sunsynk 8kW hybrid Inverter is the ideal inverter for managing power flow from multiple sources such as solar, main electrical grid and generator.Product FeaturesDual MPPT designCompatible with most Lithium-ion batteries and Lead Acid batteriesMobile App for monitoringIP65 ratedAutomatic switching from Grid-Tied to Off-Grid modeZero export functionUp to 16 units with the same firmware can be paralleledEssential and Non-Essential Loads outputsComes with the Wi-Fi logger and CTCompatible with SolarMan App for Monitoring   Sunsynk-8.8-K-SG01LP1 ECCOWeight: 25 kgRated Power: 8,000 WMin PPT Voltage: 125 VMax PPT Voltage: 425 VDC Startup Voltage: 150 VDC Shutdown Voltage: 150 VMax Input Voltage: 500 VMax DC Power: 10,400 WMax AC Power (5 Minutes): 8,001 WSurge AC Power (1 Second): 8,002 WMax DC Current: 44 AMax DC Inputs: 2Has DC Fuses: 0Connector: MC4Included Connectors: 0Euro Efficiency:96.5 %Transformer:NoneMPPT Quantity: 2Has Integrated DC Switch: Yes   GSL 10.24kwh LiFePO4 battery         Key information 10yr battery warranty & 5yr inverter warranty 90% D.O.D 6,000 life cycle Maximum PV input power: 6500W Maximum charge current: 100A   Product Performance 1. This is a multi-function inverter/charger/solar system. 2. Combining functions of inverter, solar charger and battery to offer uninterruptible power support with portable size. 3. LCD display, configure input voltage range for home appliances and personal computers, configure battery charging current based on applications, configure AC/Solar Charge priority. 4. Compatible to mains voltage or generator power, auto restart while AC is recovering. 5. Users can flexibly match battery capacity, standard battery packages or external batteries. 6. It combines a wide PV input range MPPT controller, can convert solar energy from PV to loads directly. 7. Integrated design, Easy transportion and installation. 8. Overload/Over temperature/short circuit protection. 9. Our product are CE/ ROSH/ VDE/ MSDS/ UN38.3/ IEC approved, meeting various certification requirements for different countries.     Product Features: -Safety; LiFePO4 LFP Battery, stable and safe. Module, pack, system, triple protection.   -Simple Modular design, single person con carry and install it. Space saving; 0.15 sqm foot print.   -Interconnection Global cloud plaform Mobile APP. Anytime and anywhere. Open APL, support power internet applications.   Take complete control of your inverter by using the Sunsynk App.   Start by visiting the Apple App Store, or Google play store and searching "Sunsynk Logger". Alternatively, open your prefered web browser and search www.sunsynk.net.   Real time push notifications. For example Instant notification if you have a power cut or you are running on generator, or batteries   Change all settings remotely. Our data logger allows you to change and edit all settings remotely from anywhere in the world, provided that you have an Internet connection.   Complete control over your Hybrid Inverter. Using our data logger gives you complete control over your hybrid inverter. You will gain access to features that cannot be accessed via the inverter control panel, such as the update / upgrade feature to update the inverter operating system yourself.   Real-time monitoring. The majority of our app works in real-time including any changes that you make will instantly update on your inverter.   Live stats and monitoring. You have access to multiple stats including live monitoring and reporting. Using this app allows you to see peaks in your energy usage, you can then customize your system to work around this to help you save money on your electricity bills.   Reporting. Generate custom reports and graphs to help you monitor and understand how your system is working and where you are saving money.     Real-time monitoring. The majority of our app works in real-time including any changes that you make will instantly update on your inverter.

18 x panel 9kW solar & 10.24kWh battery storage with choice of panels Typical summer day expected daily generation: 36 kw Typical winter day expected daily generation: 9kw Battery storage charge/discharge rate: up to 5kwh Sunsynk 8Kw Data Sheet Sunsynk 8Kw Installation Manual Sunsynk 8Kw Warranty Sunsynk 8Kw G99 Certificate Sunsynk hybrids have the API to connect to Octopus Agile & Flux to buy electricity at cheap rates and even sell back to the national grid at high rates through SEG payments. Our complete solar pv & battery storage kit includes: 18 x Solar panels, any solar panels can be selected from our website of up to £60+vat cost price typically 450-525W 1 x GSL 10.24kwh storage (For additional batteries please add to your cart GSL 10.24kw battery) 1 x SunSynk On & Off grid 8kW AC ECCO hybrid Inverter 18 x Mounting equipment for standard pitched roof in portrait orientation. For Alternative mounting requirements please request a quote. 1 x Electrics pack including solar cable, MC4's, pre-terminated cable, AC & DC Isolators, bi-directional meter The Sunsynk 8kW hybrid Inverter is the ideal inverter for managing power flow from multiple sources such as solar, main electrical grid and generator.Product FeaturesDual MPPT designCompatible with most Lithium-ion batteries and Lead Acid batteriesMobile App for monitoringIP65 ratedAutomatic switching from Grid-Tied to Off-Grid modeZero export functionUp to 16 units with the same firmware can be paralleledEssential and Non-Essential Loads outputsComes with the Wi-Fi logger and CTCompatible with SolarMan App for Monitoring   Sunsynk-8.8-K-SG01LP1 ECCOWeight: 25 kgRated Power: 8,000 WMin PPT Voltage: 125 VMax PPT Voltage: 425 VDC Startup Voltage: 150 VDC Shutdown Voltage: 150 VMax Input Voltage: 500 VMax DC Power: 10,400 WMax AC Power (5 Minutes): 8,001 WSurge AC Power (1 Second): 8,002 WMax DC Current: 44 AMax DC Inputs: 2Has DC Fuses: 0Connector: MC4Included Connectors: 0Euro Efficiency:96.5 %Transformer:NoneMPPT Quantity: 2Has Integrated DC Switch: Yes   GSL 10.24kwh LiFePO4 battery Key information 10yr battery warranty & 5yr inverter warranty 90% D.O.D 6,000 life cycle Maximum PV input power: 6500W Maximum charge current: 100A Product Performance 1. This is a multi-function inverter/charger/solar system. 2. Combining functions of inverter, solar charger and battery to offer uninterruptible power support with portable size. 3. LCD display, configure input voltage range for home appliances and personal computers, configure battery charging current based on applications, configure AC/Solar Charge priority. 4. Compatible to mains voltage or generator power, auto restart while AC is recovering. 5. Users can flexibly match battery capacity, standard battery packages or external batteries. 6. It combines a wide PV input range MPPT controller, can convert solar energy from PV to loads directly. 7. Integrated design, Easy transportion and installation. 8. Overload/Over temperature/short circuit protection. 9. Our product are CE/ ROSH/ VDE/ MSDS/ UN38.3/ IEC approved, meeting various certification requirements for different countries. Product Features: -Safety; LiFePO4 LFP Battery, stable and safe. Module, pack, system, triple protection. -Simple Modular design, single person con carry and install it. Space saving; 0.15 sqm foot print. -Interconnection Global cloud plaform Mobile APP. Anytime and anywhere. Open APL, support power internet applications. Take complete control of your inverter by using the Sunsynk App. Start by visiting the Apple App Store, or Google play store and searching "Sunsynk Logger". Alternatively, open your prefered web browser and search www.sunsynk.net. Real time push notifications. For example Instant notification if you have a power cut or you are running on generator, or batteries Change all settings remotely. Our data logger allows you to change and edit all settings remotely from anywhere in the world, provided that you have an Internet connection. Complete control over your Hybrid Inverter. Using our data logger gives you complete control over your hybrid inverter. You will gain access to features that cannot be accessed via the inverter control panel, such as the update / upgrade feature to update the inverter operating system yourself. Real-time monitoring. The majority of our app works in real-time including any changes that you make will instantly update on your inverter. Live stats and monitoring. You have access to multiple stats including live monitoring and reporting. Using this app allows you to see peaks in your energy usage, you can then customize your system to work around this to help you save money on your electricity bills. Reporting. Generate custom reports and graphs to help you monitor and understand how your system is working and where you are saving money. Real-time monitoring. The majority of our app works in real-time including any changes that you make will instantly update on your inverter.

20 x panel 10kW solar & 10.24kWh battery storage with choice of panels Typical summer day expected daily generation: 40kw Typical winter day expected daily generation: 10kw Battery storage charge/discharge rate: up to 5kwh Sunsynk 8Kw Data Sheet Sunsynk 8Kw Installation Manual Sunsynk 8Kw Warranty Sunsynk 8Kw G99 Certificate   Sunsynk hybrids have the API to connect to Octopus Agile & Flux to buy electricity at cheap rates and even sell back to the national grid at high rates through SEG payments.   Our complete solar pv & battery storage kit includes: 20 x Solar panels, any solar panels can be selected from our website of up to £60+vat cost price typically 450-525W 1 x GSL 10.24kwh storage (For additional batteries please add to your cart GSL 10.24kw battery) 1 x SunSynk On & Off grid 8kW AC ECCO hybrid Inverter 20 x Mounting equipment for standard pitched roof in portrait orientation. For Alternative mounting requirements please request a quote. 1 x Electrics pack including solar cable, MC4's, pre-terminated cable, AC & DC Isolators, bi-directional meter The Sunsynk 8kW hybrid Inverter is the ideal inverter for managing power flow from multiple sources such as solar, main electrical grid and generator.Product FeaturesDual MPPT designCompatible with most Lithium-ion batteries and Lead Acid batteriesMobile App for monitoringIP65 ratedAutomatic switching from Grid-Tied to Off-Grid modeZero export functionUp to 16 units with the same firmware can be paralleledEssential and Non-Essential Loads outputsComes with the Wi-Fi logger and CTCompatible with SolarMan App for Monitoring   Sunsynk-8.8-K-SG01LP1 ECCOWeight: 25 kgRated Power: 8,000 WMin PPT Voltage: 125 VMax PPT Voltage: 425 VDC Startup Voltage: 150 VDC Shutdown Voltage: 150 VMax Input Voltage: 500 VMax DC Power: 10,400 WMax AC Power (5 Minutes): 8,001 WSurge AC Power (1 Second): 8,002 WMax DC Current: 44 AMax DC Inputs: 2Has DC Fuses: 0Connector: MC4Included Connectors: 0Euro Efficiency:96.5 %Transformer:NoneMPPT Quantity: 2Has Integrated DC Switch: Yes   GSL 10.24kwh LiFePO4 battery Key information 10yr battery warranty & 5yr inverter warranty 90% D.O.D 6,000 life cycle Maximum PV input power: 6500W Maximum charge current: 100A Product Performance 1. This is a multi-function inverter/charger/solar system. 2. Combining functions of inverter, solar charger and battery to offer uninterruptible power support with portable size. 3. LCD display, configure input voltage range for home appliances and personal computers, configure battery charging current based on applications, configure AC/Solar Charge priority. 4. Compatible to mains voltage or generator power, auto restart while AC is recovering. 5. Users can flexibly match battery capacity, standard battery packages or external batteries. 6. It combines a wide PV input range MPPT controller, can convert solar energy from PV to loads directly. 7. Integrated design, Easy transportion and installation. 8. Overload/Over temperature/short circuit protection. 9. Our product are CE/ ROSH/ VDE/ MSDS/ UN38.3/ IEC approved, meeting various certification requirements for different countries. Product Features: -Safety; LiFePO4 LFP Battery, stable and safe. Module, pack, system, triple protection. -Simple Modular design, single person con carry and install it. Space saving; 0.15 sqm foot print. -Interconnection Global cloud plaform Mobile APP. Anytime and anywhere. Open APL, support power internet applications. Take complete control of your inverter by using the Sunsynk App. Start by visiting the Apple App Store, or Google play store and searching "Sunsynk Logger". Alternatively, open your prefered web browser and search www.sunsynk.net. Real time push notifications. For example Instant notification if you have a power cut or you are running on generator, or batteries Change all settings remotely. Our data logger allows you to change and edit all settings remotely from anywhere in the world, provided that you have an Internet connection. Complete control over your Hybrid Inverter. Using our data logger gives you complete control over your hybrid inverter. You will gain access to features that cannot be accessed via the inverter control panel, such as the update / upgrade feature to update the inverter operating system yourself. Real-time monitoring. The majority of our app works in real-time including any changes that you make will instantly update on your inverter. Live stats and monitoring. You have access to multiple stats including live monitoring and reporting. Using this app allows you to see peaks in your energy usage, you can then customize your system to work around this to help you save money on your electricity bills. Reporting. Generate custom reports and graphs to help you monitor and understand how your system is working and where you are saving money. Real-time monitoring. The majority of our app works in real-time including any changes that you make will instantly update on your inverter.

Concrete Ballast Block 17kgs #2: BALLAST-17KG Mounting - Flat Roof Ballast Data Sheet Ballast Block - Install Guide   Only available to purchase together with solar panels or mounting The Enviroblock ® is a Solid Dense 7.3N Concrete Block. It is manufactured from secondary and recycled materials and comes in a natural grey finish. Durable and non-penetrable, it can be used with all ballasted mounting solutions for domestic, industrial and commercial flat roof installations to maximise harvesting of solar power. Specs: Height: 215 mmLength: 440 mmWidth: 100 mmWeight approx. 17 kgs

Current Transformer 100A (incl. fly lead) #1: CT-100A Display - Current Sensor Clamps 100A Current Transformer clamp Split Core CT Series Frequency: 50-60Hz Accuracy: ±1% between 20% - 120% Insulation voltage: 600V AC Maximum primary voltage: 5000V AC Dielectric strength: 2.5KV/1mA/1min Operating temperature: -15 °C to +60 °C Operating humidity: <85% Case material: PC / UL94-V0 Bobbin: PBT Core: Permalloy Internal structure: Epoxy Split core Current Transformer incl fly lead Part No as per datasheet: SCT24 100\5 Keywords: Landis, Display, Current Sensor Clamp

Current Transformer 200A (incl. fly lead) #1: CT-200A Display - Current Sensor Clamps 200A Current Transformer clamp Split Core CT Series Frequency: 50-60Hz Accuracy: ±1% between 20% - 120% Insulation voltage: 600V AC Maximum primary voltage: 5000V AC Dielectric strength: 2.5KV/1mA/1min Operating temperature: -15 °C to +60 °C Operating humidity: <85% Case material: PC / UL94-V0 Bobbin: PBT Core: Permalloy Internal structure: Epoxy Split core Current Transformer ( incl. fly lead ) Part No as per datasheet: SCT24 200\5 Keywords: Landis, Display, Current Sensor Clamp

Current Transformer 500A (incl. fly lead) #1: CT-500A Display - Current Sensor Clamps SCT36-500/5A Split Core Current Transformer 500A Current Transformer clamp Frequency: 50-60Hz Accuracy: ±1% between 20% - 120% Insulation voltage: 600V AC Maximum primary voltage: 5000V AC Dielectric strength: 2.5KV/1mA/1min Operating temperature: -15 °C to +60 °C Operating humidity: <85% Case material: PC / UL94-V0 Bobbin: PBT Core: Permalloy Internal structure: Epoxy Split core Current Transformer ( incl. fly lead ) Part No as per datasheet: SCT36-500/5A

Custom Product / System

Dektite Lead Multicable Solar Flashing (Tiled or Slate) #2:DNLS10MB Mounting - Cable Flashings Dektite Datasheet Dektite Installation Guide Dektite Warranty Per the MCS Installation Guide "cable penetrations through the roof should not affect the weather tightness of the roof and should be durably sealed." Dektite's Multicable is a simple, effective and universal way to meet this requirement At the same time it protects the cables from compression or damage from contact with roofing materials. Features Product per MCS standard Universal - fits all types of tile and slate roofs Quick, easy install - only tool required are cable snips Nu-Lead base [acrylic coated lead] for perfect dressing with profiled tiles Safe handling, no staining Base size 490 x 410mm, easily cut down if necessary Dektite quality EPDM seal protects up to 10 cables from compression or damage by isolation from contact with roofing materials 20 year warranty

Deposit Payment for Installation Secure your installation with a deposit of £750 (0% VAT applied at checkout). This payment initiates the process, including the DNO application where applicable, and helps coordinate an installation date. Steps to Proceed: Provide details of the system you require. MPAN Number  Photo's of the space for the battery system with a description of the location Photo's of the consumer unit with description of location of consumer unit in relation to the location for the battery system. Photo's of a current solar inverter set up if relevant.  The deposit is deducted from the total cost of the installed package and is fully refundable until the system is dispatched for delivery. The balance payment is due 3-4 days before installation to allow time to book in delivery of your system.

Double pair genuine RS485 cable 1M - 4 cores Part No: RS485-DOUBLE-1M Storage Systems - Communication CablePRICE PER METERLSZH 440Series 2x2x24awg RS-485 600 V – TREND system use : BACnet ® over MS/TPCable Construction Conductor - Stranded tinned copper wire, 24awg Insulation - Polyethylene (PE) Formation - 4 cores twisted as two pairs. BLUE/white - WHITE/blue and ORANGE/white - WHITE/orange Screen - Overall Aluminium/Polyester tape Drain Wire - Stranded tinned copper wire, 24awg Braid - Tinned copper wire braid, 80% coverage Outer Jacket - LSZH FireFighter ® UV-Stable

Duracell Energy Dura-i 3.6kW Hybrid Inverter PD-DH1P-3.6-G1 #5: Duracell Energy Dura-i 3.6kW Hybrid Inverter PD-DH1P-3.6-G1 Duracell Inverter Data Sheet Duracell Inverter Manual Duracell's Energy Dura-i 3.6kW Hybrid Inverter PD-DH1P-3.6-G1 is designed to elevate your solar energy potential. Crafted with Duracell's hallmark of steadfast reliability and innovation, this hybrid inverter is an excellent option for your solar energy setup. Features Hybrid and AC compatible Up to 97.3% efficiency Integrated energy meter Modular - up to 6 parallel inveters Compatible with Dura5 Battery 5 year standard warranty, 10 years optional Specs Weight: 25kg Max efficiency: 97.3% (PV to AC) Max efficiency: 94.30% (BAT to AC) Max PV Power: 9,000 W Max PV Voltage: 550 V Max charge/discharge: 60 A Max charge/discharge: 3,000 W No of MPPT: 2 String per MPPT: 1 AC output power: 3,960 W Output current: 13,1 A Rated voltage: 230 V Dimensions: 585 x 485 x 175 (mm) Installation: wall mount DC Switch Operating temperature: -25 °C~+60 °C Display: LED Communication Ports: CAN / RS485

Duracell Energy Dura-i 4.6kW Hybrid Inverter PD-DH1P-4.6-G1 #5: DURACELL-PD-DH1P-4.6-G1 Duracell Inverter Data Sheet Duracell Inverter Manual   Duracell's Energy Dura-Dura-i 4.6kW Hybrid Inverter PD-DH1P-4.6-G1, is designed to elevate your solar energy potential. Crafted with Duracell's hallmark of steadfast reliability and innovation, this hybrid inverter is an excellent option for your solar energy setup. Features Hybrid and AC compatible Up to 97.3% efficiency Integrated energy meter Modular - up to 6 parallel inveters Compatible with Dura5 Battery 5 year standard warranty, 10 years optional Specs Weight: 25kg Max efficiency: 97.3% (PV to AC) Max efficiency: 94.30% (BAT to AC) Max PV Power: 9000 W Max PV Voltage: 550 V Max charge/discharge: 120A Max charge/discharge: 5000 W No of MPPT: 2 String per MPPT: 1 AC output power: 4,600 VA Output current: 22 A Rated voltage: 230 V Nominal capacity: 100 Dimensions: 585 x 485 x 175 (mm) Installation: wall mount Operating temperature: -25 °C~+60 °C Display: LED Communication Ports: CAN / RS485

Duracell Energy Dura-i 5kW Hybrid Inverter PD-DH1P-5-G1 #5: DURACELL-PD-DH1P-4.6-G1 Duracell Inverter Data Sheet Duracell Inverter Manual   Duracell's Energy Dura-Dura-i 4.6kW Hybrid Inverter PD-DH1P-5-G1, is designed to elevate your solar energy potential. Crafted with Duracell's hallmark of steadfast reliability and innovation, this hybrid inverter is an excellent option for your solar energy setup. Features Hybrid and AC compatible Up to 97.3% efficiency Integrated energy meter Modular - up to 6 parallel inveters Compatible with Dura5 Battery 5 year standard warranty, 10 years optional Specs Weight: 25kg Max efficiency: 97.3% (PV to AC) Max efficiency: 94.30% (BAT to AC) Max PV Power: 9000 W Max PV Voltage: 550 V Max charge/discharge: 120A Max charge/discharge: 5000 W No of MPPT: 2 String per MPPT: 1 AC output power: 4,600 VA Output current: 22 A Rated voltage: 230 V Nominal capacity: 100 Dimensions: 585 x 485 x 175 (mm) Installation: wall mount Operating temperature: -25 °C~+60 °C Display: LED Communication Ports: CAN / RS485
