Huawei LUNA 5KWh battery pack with BMS for solar storage

Huawei LUNA 5KWh battery PACK (without BMS) £1,647.00 + VAT

Huawei LUNA 5KWh battery PACK (without BMS) #1: SUN2000-LUNA-5KWh The Power Module that manages the battery, displays information and connects to the inverter. A LUNA power system consists of a Power Module (BMS) and 1 to 3 Battery modules, make sure you have both for a complete system.

Huawei LUNA BMS (for 5kWh battery) £660.00 + VAT

Huawei LUNA BMS (for 5kWh battery) #1: SUN2000-LUNA-BMS BMS for 5kWh battery bank: The Power Module that manages the battery, displays information and connects to the inverter. A LUNA power system consists of a Power Module (BMS) and 1 to 3 Battery modules, make sure you have both for a complete system.

Huawei Smart Dongle for Wi-Fi and Ethernet networks

Huawei Smart Dongle - Wi-Fi and Ethernet Network adapter £52.00 + VAT

Huawei Smart Dongle - Wi-Fi and Ethernet Network adapter #2: HUA-SMART-WLAN-FE Huawei Smart Dongle - Wi-Fi and EthernetSDongleA-05 (HUA-SMART-WLAN-FE) is a smart communications expansion module that works with Huawei inverters (3KTL-M0 to 20KTL-M0) to implement communication between inverters and the management system using WLAN (Wireless) or FE (Fast Ethernet).A Smart Dongle can be used for daisy chaining devices using RS485 communication (inverter daisy chained, or inverters connected with other devices). A maximum of 10 devices can be connected together. When multiple inverters are connected together, only one Smart Dongle or one SmartLogger is allowed.

Huawei Smart Logger 3000A solar battery storage device

Huawei Smart Logger 3000A £418.00 + VAT

Huawei Smart Logger 3000A #1: HUA-SL-3000A Huawei Smart Logger Data Sheet Huawei Smart Logger Manual Huawei Smart Logger Warranty Huawei Smart Logger G100 Certificate The Huawei Smart Logger 3000A is dedicated to monitoring and managing a PV power generating system. It converges all ports, converts protocols, collects and stores data, and centrally monitors and maintains. SMART IEC60870-5-104 for connections to third-party monitoring systems; USB and embedded web for data reading and software upgrade; Automatically detecting equipment and assigning RS485 addresses; Remote control of active & reactive power SIMPLE Up to 80 inverters feeding into one Smart Logger; Up to 30 devices per RS485 bus; Easy to install on walls, tabletops and rails mounting RELIABLE Max. reliable communication range of 1000m; Remote configuration, automatic set-up of RS485 addresses Now with built in SPD Compatible with older Huawei -V1 inverter range and newer -M0, -H1 inverter range. 3G/4G router built in - NOT IN UNITS OFFERED IN SOUTH AFRICA .

Huawei SUN2000 15kW MB0 Three Phase Inverter £1,884.00 + VAT

Huawei SUN2000 15KTL 15kW 3phase inverter M2 range #2: SUN2000-15KTL-M2 Inverters - Main Units Huawei Sun2000 15kW Data Sheet Huawei Sun2000 15kW Manual Huawei Sun2000 15kW G99 Certificate Huawei Sun2000 Warranty This 3phase inverter has a maximum efficiency up to 98.6% with an adaptable and flexible triple MPPT. DC & AC lightning protection is integrated into the unit and the natural cooling effectively improves product reliability. Features Maximum of 2 MPPT for versatile adaption to different module types or quantities built up with different alignments Up to 4 strings intelligent monitoring and fault detection Exceptionally wide MPPT range. RS 485 and USB ports for connectivity and data management Local graphic LCD and optional remote monitoring via the NetEco portal or app. IP Rated Product Warranty 10 years Specs Weight: 25 kgRated Power: 15,000 WMin PPT Voltage: 200 VMax PPT Voltage: 950 VDC Startup Voltage: 200 VDC Shutdown Voltage: 160 VMax Input Voltage: 1,080 VMax DC Power: 22,500 WMax AC Power (5 Minutes): 15,000 WSurge AC Power (1 Second): 16,500 WMax DC Current: 44 AMax DC Inputs: 4Has DC Fuses: 0Connector: Amphenol 4Included Connectors: 4Euro Efficiency: 98.6 %Transformer: NoneMPPT Quantity : 2Has Integrated DC Switch: YesWarranty: 5 years

1 HV2600 1M DC Extension Cable £18.00 + VAT

HV2600 1M DC Extension Cable #1: FE-HV2600-EXT-1M Storage Systems - Accessory Required when installing 5+ HV2600 batteries to allow 2 stacks 1m extension cable for Fox HV2600 battery

IMO Enclosed DC Switch IP66 2 pole 1 string 16A 800V

Diagram of solar panel setup with DC and AC isolators

IMO Enclosed DC Switch IP66 2 pole 1 string 16A 800V £29.00 + VAT

Enclosed DC Switch IP66 2 pole 1 string 16A 800V #2: IMO-SI16-PEL64R-2 Switches - DC Isolators #3: 4486 Data Sheet IMO Solar Isolators are specifically designed to interrupt the DC/AC Inverter from the solar panel array. Photovoltaic installations must be equipped with DC Isolators (in accordance with IEC 60364-7-712). Features 2 Pole (1 string) IP66 Enclosure Grey Body with Black switch Switching times of less than 5ms IMO patented "Safelock" function Dimensions (mm): 180x98x107 Specs Weight: 0.25 kg Poles: 2 Max Cable: 10 mm2 Max Voltage: 1,000 V Rated Current: 16 A Rated Voltage: 600 V Rated Current: 16 A Rated Voltage: 800 V Rated Current: 0 A Rated Voltage: 0 V Rated Current: 0 A Rated Voltage: 0 V

IMO Enclosed DC Switch IP66, 4 pole, 2 string, 16A, 800V

Solar panel system with DC/AC inverter and isolator setup

IMO Enclosed DC Switch IP66 4 pole 2 string 16A 800V £33.24 + VAT

Enclosed DC Switch IP66 4 pole 2 string 16A 800V #2: IMO-SI16-PEL64R-4 Switches - DC Isolators Data Sheet IMO Solar Isolators are specifically designed to interrupt the DC/AC Inverter from the solar panel array. Photovoltaic installations must be equipped with DC Isolators (in accordance with IEC 60364-7-712). Features 4 Pole (2 string) IP66 Enclosure Grey Body with Black switch Switching times of less than 5ms IMO patented "Safelock" function Dimensions (mm): 180x98x107 Specs Weight: 0.5 kg Poles: 4 Max Cable: 10 mm2 Max Voltage: 1,500 V Rated Current: 0 A Rated Voltage: 0 V Rated Current: 16 A Rated Voltage: 600 V Rated Current: 0 A Rated Voltage: 0 V Rated Current: 16 A Rated Voltage: 800 V

IMO Stag AC Isolator 4 Pole 32 Amp switch

IMO Stag AC Isolator 4 Pole 32 Amp £17.23 + VAT

IMO Stag AC Isolator 4 Pole 32 Amp #1: IMO-IS4P32 Switches - AC Isolators #17: *32A 4-pole* AC Isolator - IMO Stag Stag AC Isolator Switch - 4 Pole Enclosed 32A AC Switch Isolator IP65 Protection Rating (enclosure) EN 60947-3 Compliant Multiple Gland Knockouts Lockable Rotary Handle Flame Retardant External Mounting Points Additional Earth Connection Interlocked Enclosure Lid Measurements H - 125 W - 100 D - 85 D (including handle) - 120 Weight: 0.52 kgRated Power: 22,144 WPoles: 4Max Cable: 10 mm2Max Voltage: 690 VRated Current: 32 ARated Voltage: 415 VRated Current: 32 A

IMO Stag AC Isolator 4 Pole 32 Amp - Single phase £17.00 + VAT

IMO Stag AC Isolator 4 Pole 32 Amp - Single phase #2: IMO-IS4P32-1P Switches - AC Isolators #3: 4993 4 Pole Enclosed 32A AC Switch Isolator Features IP65 Protection Rating (enclosure) EN 60947-3 Compliant Multiple Gland Knockouts Lockable Rotary Handle Flame Retardant External Mounting Points Additional Earth Connection Interlocked Enclosure Lid Specs Weight: 0.52 kg Rated Power: 22,144 W Poles: 3 Max Cable: 10 mm2 Max Voltage: 400 V Rated Current: 32 A Rated Voltage: 415 V Rated Current: 32 A Rated Voltage: 230 V Rated Current: 0 A Rated Voltage: 0 V Dimension: 100mm x 125mm x 85mm (w x h x d) (depth is incl. handle)

IMO Stag AC Isolator 4 Pole, 63 Amp switch

IMO Stag AC Isolator 4 Pole, 63 Amp £27.00 + VAT

IMO Stag AC Isolator 4 Pole, 63 Amp #1: IMO-IS4P63 #3: 4555 #17: IMO 63A AC Isolator 4-pole Stag AC Isolator Switch - 4 Pole Enclosed 63A AC Switch Isolator IP65 Protection Rating (enclosure) EN 60947-3 Compliant Multiple Gland Knockouts Lockable Rotary Handle Flame Retardant External Mounting Points Additional Earth Connection Interlocked Enclosure Lid Measurements H - 175 W - 115 D - 100 D (including handle) - 135 Weight: 0.75 kgRated Power: 14,490 WPoles: 4Max Cable: 16 mm2Max Voltage: 690 VRated Current: 63 ARated Voltage: 230 VRated Current: 63 ARated Voltage: 440 V

IMO Stag AC Isolator 4 Pole, 80 Amp £43.00 + VAT

IMO Stag AC Isolator 4 Pole, 80 Amp #1: IMO-IS4P80 Switches - AC Isolators #3: 4556 Stag AC Isolator Switch - 4 Pole Enclosed 80A AC Switch Isolator IP65 Protection Rating (enclosure) EN 60947-3 Compliant Multiple Gland Knockouts Lockable Rotary Handle Flame Retardant External Mounting Points Additional Earth Connection Interlocked Enclosure Lid Measurements H - 240 W - 160 D - 120 D (including handle) - 165 Weight: 1.34 kgRated Power: 18,400 WPoles: 4Max Cable: 35 mm2Max Voltage: 690 VRated Current: 80 ARated Voltage: 440 VRated Current: 80 ARated Voltage: 230 V

K&N 25A AC Switch Disconnector for solar energy systems

K&N Single Phase AC Switch Disconnector 25A in plastic enclosure

K&N Single Phase AC Switch Disconnector 25A £27.00 + VAT

K&N Single Phase AC Switch Disconnector 25A #2: KG20-T203-GBA294 Switches - AC Isolators Kraus & Naimer AC Switch Suitable for single phase AC connection. Features Plastic EnclosuresProtection IP66, totally insulated, knock-outs Handle red in the OFF-position lockable with padlocksinterlocked with lid to prevent opening in "ON" position Specs Weight: 0.46 kgRated Power: 5,750 WPoles: 3Max Cable: 10 mm2Max Voltage: 230 VRated Current: 25 ARated Voltage: 230 VDimensions: 100mm x 190mm x 93mm 9 (w x h x d) )plate backing grey

K&N Single Phase AC Switch Disconnector 32A £31.00 + VAT

K&N Single Phase AC Switch Disconnector 32A #2: KG32-T203-GBA294 Switches - AC Isolators Kraus & Naimer DC Switch Suitable for single phase AC connection. Plastic Enclosures, Protection IP66, totally insulated, knock-outs Handle red, in the OFF-position lockable with padlocks, Plate Backing grey Dimensions (w x h x d): 100mm x 190mm X 93mm Switch interlocked with lid to prevent opening in "ONE" position Weight: 0.45 kgRated Power: 7,360 WPoles: 3Max Cable: 10 mm2Max Voltage: 230 VRated Current: 32 ARated Voltage: 230 V

K&N 40A AC Switch Disconnector for solar energy

K&N Single Phase AC Switch Disconnector 40A £43.00 + VAT

K&N Single Phase AC Switch Disconnector 40A #2: KG41-T203-GBA270 Switches - AC Isolators Kraus & Naimer DC Switch Suitable for single phase AC connection. Features Plastic EnclosuresProtection IP66, totally insulated, knock-outs Handle red in the OFF-position lockable with padlocksinterlocked with lid to prevent opening in "ONE" position Specs Weight: 0.63 kgRated Power: 9,200 WPoles: 3Max Cable: 10 mm2Max Voltage: 230 VRated Current: 40 ARated Voltage: 230 VDimensions: 100mm x 190mm x 93mm 9 (w x h x d) )plate backing grey

K&N Single String DC Switch Disconnector 21A 800V - 20A 1000V £48.00 + VAT

K&N Single String DC Switch Disconnector 21A 800V - 20A 1000V #2: KG20B-T106Dï»¿ Switches - AC Isolators Kraus & Naimer DC Switch Switch Disconnectors. 2 pole for single string Features IP66/67 protectionBlack Grey padlockable handle - lockable in the 'OFF' positionClass II compliant, Grey insulated enclosureSwitch interlocked with lid to prevent opening in 'ON' position Specs Weight: 0.68 kgRated Power: 9,600 WPoles: 2Max Cable: 6 mm2Max Voltage: 1,000 VRated Current: 21 ARated Voltage: 800 VRated Current: 20 ARated Voltage: 1000 VDimensions: 100mm x 190mm x 93mm 9 (w x h x d) )plate backing grey
