EcoFlow PowerOcean Plus 29.9kW 3-Phase Hybrid Inverter
#3: 6871 Storage Systems - Hybrid Inverter
EcoFlow PowerOcean Plus Hybrid Brochure
EcoFlow PowerOcean Plus Hybrid Datasheet
EcoFlow PowerOceean Plus Hybrid User Manual
EcoFlow PowerOcean Plus G99 Certification
EcoFlow App Manual
EcoFlow PowerOcean Plus Warranty
Easy Power Independence for Your Home or Business
The EcoFlow PowerOcean Plus 29.9kW 3-Phase Hybrid Inverter is a high-capacity energy solution designed for large residential homes, commercial buildings, and high-demand solar systems. Combining powerful solar input, advanced safety features, and smart energy management, this inverter is ideal for anyone seeking scalable, secure, and future-ready power independence.
Equipped with LFP (LiFePO4) battery compatibility, a built-in fire prevention module, and a robust IP65-certified design, the PowerOcean Plus sets the standard in reliability and performance. Monitor and control your entire energy system in real time using the EcoFlow App and Web Portal.
Key Features
Built for High-Demand Systems
-
Delivers up to 29.9kW of AC output, perfect for large homes, multi-phase equipment, or light commercial applications
-
Supports 3-phase power, ensuring stability for heavy-load appliances like EV chargers, heat pumps, and HVAC systems
-
Compatible with high-capacity solar arrays and battery banks
Scalable & Long-Lasting Storage
-
Battery storage expandable up to 60kWh
-
Supports 6,000+ battery charge cycles
-
Modular plug-and-play expansion for future-proof installations
Intelligent Monitoring & Efficiency
-
Manage solar input, battery levels, and energy usage from anywhere via the EcoFlow App and Web Portal
-
98.0% peak efficiency for maximum solar energy utilisation
-
Designed to reduce reliance on the grid and optimise ROI from your solar investment
Technical Specifications
AC Output
DC Input (Solar PV)
-
Max PV Input Power:
-
20kW (PV1 input)
-
10kW (PV2 & PV3 inputs)
-
Max Short-Circuit Current (Isc):
-
19A × 2 (PV1 input)
-
24A (PV2/PV3 input)
-
Max Current per MPPT: 16A
-
Strings per MPPT:
-
2 (PV1 input)
-
1 (PV2/PV3 input)
-
Number of MPPTs: 3 (1 per PV input)
-
MPPT Voltage Range: 200V – 850V
-
Start-up Voltage: 160V
-
Max PV Voltage: 1000V
System & Build
-
Maximum Efficiency: 98.0%
-
IP Rating: IP65 (dust-tight and water-resistant)
-
Weight: 40.75kg
-
Dimensions: 636mm × 235mm × 498mm
What's in the Box
- EcoFlow PowerOcean Plus 29.9kW Hybrid Inverter
- Installation and mounting accessories
- User manual and setup guide
- Access to EcoFlow App & Web Portal
Why Choose the EcoFlow PowerOcean Plus 29.9kW Three Phase Inverter:
Ideal for:
-
Large residential homes with high energy consumption
-
Light commercial properties needing stable 3-phase output
-
Renewable energy enthusiasts looking for full or partial off-grid capability
-
Installers and developers designing scalable solar + storage systems
