- Material:Β Stainless steel A2
- Diameter of sealing collar: 25 mm
- Sealing integrated: Yes
- Thread Diameter: M12; 11.0mm
- Thread: Partial thread
- Thread applicable for: Wood
- Metric Thread length: 100.0 mm
- Head of Screw: Hexagon head
- Screw penetration: 60 mm
- Screw tip: Wood top
- Space for adjustment vertical:Β 91,00 mm
- Assembly without pre-drilling: 8.4 mm
- Compatible with product groups: VarioSole SE
- TriSole Material: Stainless steel, AluminumΒ Β
Other contents include:
- 1 x 900002 Hanger bolt M12 x 250
- 1 x 900007 Hammerhead bolt M8x25
- 1 x 900001 Hexag. nut DIN6923 - M8 A2-70 with FL & SZ
- 1 x 400012 Standard Bracket M12
Please note: Do note use Renusol mounting equipment with mounting equipment from other suppliers. This will void the warranty of the mounting system.
