Sunsynk 50kW 3PH Hybrid Inverter with 40.96kWh Battery

Sunsynk 50kW 3PH Hybrid Inverter with 40.96kWh Battery

#2: SUN-3PH-50K-BATT-40.96 Storage Systems - Storage Package

Sunsynk 3ph 50kW Data Sheet

Sunsynk 3ph 50kW User Manual

Sunsynk 3ph 50kW Warranty

To view our full range of Sunsynk products visit our main Sunsynk page here

Sunsynk 50kW HV Three Phase Hybrid Inverter System

System Components

This commercial and industrial hybrid system includes:

• 1 × Sunsynk 50kW HV Three Phase Hybrid Inverter (SUN-50.0-3PH)

• 8 × Sunsynk 5.12kWh Single Battery Unit for HV Series (SUN-HV-5.12-BATT)

• 2 × BMS for Sunsynk HV Series (SUN-HV-BMS)

• 2 × Battery Cabinets with Door for Sunsynk 20.48kWh HV Battery (SUN-HV-20.48-BATTRACK-DOOR)

Product Overview

The Sunsynk 50kW HV Three Phase Hybrid Inverter is specifically designed for commercial and industrial properties. It allows efficient management of power flow from multiple sources such as solar panels, the main electrical grid, and generators. With remote monitoring available through the Sunsynk App, this inverter ensures optimal performance and easy maintenance.

Important: This product must be installed by a qualified technician. Installations must adhere to local wiring regulations and standards; otherwise, the warranty will be invalid.

Key Features

• Flexible PV Configurations: 4 MPPT trackers for maximum adaptability

• DC Oversizing: Supports DC input up to 30% higher than rated AC power

• Battery Flexibility: Can operate independently without batteries

• Remote Monitoring: WiFi connectivity included as standard

• Safety First: Type II DC/AC SPD included, plus overload, over-temperature, and short-circuit protection

Technical Specifications

Power & Input

• Rated Power: 50,000 W

• Max DC Power: 65,000 W

• Max AC Power (5 minutes): 50,000 W

• Surge AC Power (1 second): 55,000 W

• Min PPTV Voltage: 150 V

• Max PPTV Voltage: 850 V

• DC Startup Voltage: 180 V

• DC Shutdown Voltage: 150 V

• Max Input Voltage: 1,000 V

• Max Discharge Current: 144 A

• Max DC Fuses: 0

• MPPT Quantity: 4

Electrical & Efficiency

• Connector: MC4

• Included Connectors: 0

• Euro Efficiency: 97%

• Transformer: None

• Integrated DC Switch: Yes

Physical Attributes

• Weight: 75 kg

Warranty

• 5-year standard warranty
