Enphase IQ7A 3ph 60 and 72 cell MC4 integrated Microinverter 230 & 400VAC £131 + vat

£157.20 incl. VAT

Enphase IQ7A 3ph 60 and 72 cell MC4 integrated Microinverter 230 & 400VAC £131 + vat

£157.20 incl. VAT
Product description

Enphase IQ7A 60 and 72 cell MC4 integrated Microinverter 230 & 400VAC

#1: Part No: EN-IQ7A-72-M-INT-3PH Inverters - Micro Inverter Units

Pdf free icon Enphase IQ7a Data Sheet

Pdf free icon Enphase IQ7a Manual

Automatic discount for 14+: £6/unit

Automatic discount for 22+: £8/unit

*Collections are not permitted due to health & safety regulations*

  • Rating: 500W
  • Phases: 3

Product Features:

  • High performance version of the seventh-generation IQ platform
  • Smart-Grid ready
  • Easily integrated with the Gateway-S™ and Enphase™ monitoring and analysis software
  • Easy to install thanks to lightweight design and improved two-wire cabling
  • Double insulated housing, protection class II
  • Modular design allows simple expansion of system as required
  • Ultra reliable – system keeps working even if a single panel/microinverter fails or panel slips into shade
  • Mobile app allows enhanced control and monitoring possibilities
  • Commonly used module pairings: 295W - 460W +
  • Module compatibility: 60-cell/120 half-cell and 72-cell/144 half-cell PV modules
  • Peak output power: 366 VA
  • Operating range: 18V - 58V
  • IP Rating: IP67

Weight: 1.08 kg
Rated Power: 500 W
Min PPT Voltage: 38 V
Max PPT Voltage: 43 V
DC Startup Voltage: 33 V
DC Shutdown Voltage: 32 V
Max Input Voltage: 58 V
Max DC Power: 500 W
Max AC Power (5 Minutes): 366 W
Surge AC Power (1 Second): 349 W
Max DC Current: 10.2 A
Max DC Inputs: 1
Has DC Fuses: 0
Connector: MC4
Included Connectors: 0
Euro Efficiency: 96.5 %
Transformer: HF
MPPT Quantity : 1
Has Integrated DC Switch: No
Warranty: 25 years
