Fox Energy Cube HV ECS2900 V2 2.88kWh Slave Battery Connector Type B £751 + VAT

Fox Energy Cube HV ECS2900  V2 2.88kWh Slave battery Connector Type B

#1: FE-HV-ECS-2900

 Fox ECS2900 Datasheet

 Fox ECS2900 Manual

 Fox ECS2900 Warranty

*Cube batteries from ITS are  V2 if purchasing to add to an existing system please check if you have V2 with B connector batteries on your existing system.

Suitable for charging from the grid such as Economy 7 & Octopus Go. For detailed explanation of how to maximize Economy 7 essential information to work out which battery storage options is best for you please visit - Understanding Economy 7

Compatible with Fox HV chargers only available on our Fox HV main page

*Collections are not permitted due to health & safety regulations*

Energy cube is a high-performance, scalable battery storage system. The modular design allows for maximum flexibility, making it suitable for a broad range of storage applications. Additional batteries can be installed in series, allowing for a maximum storage capacity of 20.16 kWh. Installation is easy, with a plug and play solution that can save valuable time for installers.

• 2.88kWh Capacity
• Scalable to 20.16kWh
• 90% Depth of Discharge
• Wide Temperature Tolerence
• Easy Installation
• CAN/RS485 Communication
• High Voltage

Weight: 32.4 kg
Battery Type: Lithium Ion
Nominal Energy: 2880 Wh
Depth of discharge: 90.00 %
Voltage: 52 V
Continuous Discharge Rate (Normal Use): 1440 W
Maximum Discharge Rate (5 Minutes): 2880 W
Surge Discharge Rate (15 Seconds): 3000 W
Maximum Charge Rate (5 Minutes): 2880 W
